Stakemill now offers Omnidirectional Scanner Target w/ Female 5/8 x 11 EMF from SECO



larger image

Omnidirectional Scanner Target w/ Female 5/8 x 11 EMF

PURCHASE HERE

$185.00

Omnidirectional Scanner Target w/ Female 5/8 x 11 Adapter EMF

The new omnidirectional ball or sphere target, for use with laser scanners, is now available from SECO.

This target is 6 inches round and has a new coating makingit more reflective to the laser scanners, only Stakemill has thes in stock ready to ship.

The target height is 150 mm.

This target is compatible with all standard surveying equipment; tribrachs, poles, etc.

The #6701-00 base features a female 5/8 x 11 adapter.

Accessories sold separately include: #6700-050 Quick Disconnect adapter; #8081-00-ORG padded bag, #8130-00-ORG padded bag (which holds target with tribrach and adapter); #2152-04-BLK optical plummet; #2070-00 tribrach adapter; #5507 series 150 mm height poles; #5218 series pole bipod or tripod.

It weighs 5.3 lb (2.4 kg)



Rolatape 32-401 NEW 15.5 Inch Professional Counter Wheel

Buy Here

Rolatape 32-401 NEW 15.5 Inch Professional Counter Wheel

32-401 When a tough, all-purpose metric measuring wheel is needed, nothing fills the order like the Rolatape 401 (Spoked) Wheel. These?15.5 Inch?circumference wheels that Stakemill offers handle the toughest measuring needs for heavy construction, large commercial operations, utility companies, land surveying and other critical measuring app 401 APPLICATIONS Large Commercial Projects Paved/Unpaved/Gravel Roads Street Opening Surveys Utility Installations Surveying Track and Field Events

401 FEATURES BENEFITS All Steel Construction Heavy-duty strength and durability 5 Digit counter is easy to read and impact resistant Records up to 9,999 with convenient reset knob Long lasting rubber tread for good non slip grip and long lasting operation on any surface Wheel stand keeps wheel upright when not in use Positive metal handle latch makes going from storage to operation easy Transport to second site without losing existing measurements Sealed construction protects gear drive from dust and debris Spoked Wheel lighter to carry SPECIFICATIONS Model 401 Suggested Retail Price $150.00 Measure Units Feet/Inches Counter Type Single Counter Limit 9,999 Wheel Type Steel Spoked NOTE: Due to varying field conditions and operator usage, measuring wheels should only be used as estimating tools.

Stakemill is one of Sokkia’s Top Ten Survey Supplies Resellers

http://www.stakemill.com/index.php?main_page=index&manufacturers_id=19

Stakemill has finished the prior years sales as one of Sokkias Top 10 in  resales of survey products, we have almost 400 products from Sokkia so it’s no accident we were able to move these quality survey products.  See our website or stop into our Florida showroom to see our stock of Sokkia products.

It takes a friendly and knowledgeable sales staff, but more importantly it takes having sales reps informing your customers of the products you offer. Many customers no longer look at a paper catalog as they are now a thing of the past, it falls back on good old-fashioned face to face sales, a service not seen by many of our Florida competitors.  Stop in and met the owners of Stakemill while they cover floor time selling and demoing product.

Shop online for Land Survey Supplies and GIS Receivers at Stakemill http://www.stakemill.com

Download Spectra Precision Survey Pro Software Before You Buy

http://www.spectraprecision.com/spectra-precision-software-downloads.aspx

Downloads GNSS/GPS Downloads EPOCH 50 EPOCH 35 EPOCH 25 – v232 Field/Office Software Downloads Survey Pro Survey Office Foresight Other Downloads NEW! Spectra Precision Field Surveyor 2.1.1 GPS configurator SP – v3525

LTI MapStar and TruAngle Demo Days at Stakemill

BUY HERE

LTI Range Finders

Stakemill has teamed up with LTI’s Bryan Willis to provide one on one training to those who have purchased LTI Impuse or TruPulse units from us at Stakemill.  We offer product orientation on the Impulse and TruPulse lasers along with the TruAngle device and MapStar software on a Recon data collector.

FCC Narrowbanding Requirements for UHF Transmission in the US

Most UHF radio licenses in the US are for the 450-470 MHz band. In the past the FCC divided this 20 MHz band into 800, 25 kHz-wide channels in order to allow each user to operate with his own licensed frequency. Federal frequency coordinators have allocated these 800 channels to users in various geographic regions around the country. As UHF usage increased, some regions ran out of channels. Accordingly, in 1995 the FCC announced a three-phase plan to double the number of channels to 1600 by licensing operation in narrower, 12.5 kHz channels. The three phases are:

Phase I: Restrictions on the certification of new radios

Phase II: Restrictions on new licenses

Phase III: Restrictions on all licenses

The FCC implemented

Phase I in 1997 when they began certifying radios only if they were capable of operating in 12.5 kHz or narrower channels, or with spectral efficiency equivalent to 4800 bps in a 6.25 kHz channel. This “spectral efficiency” clause means a radio can operate in a 25 kHz channel if it transmits at least 19200 bps. All Pacific Crest radios certified since 1997 have met this narrowbanding definition: they either operate in 12.5 kHz channels or they transmit 19200 bps in a 25 kHz channel. Some can do both.

On 1/1/11, the FCC implemented Phase II of the narrowbanding plan and started issuing new 25 kHz licenses only in rural areas or for special purposes. These licenses were rare. When 25 kHz licenses came up for renewal, they were almost always replaced with 12.5 kHz licenses. Pacific Crest believes it is prudent to assume that the FCC will not grant any 25 kHz licenses after 1/1/11. But if you do get a 25 kHz license, it will require you to transmit at least 19200 bits per second.

On 1/1/13, the FCC will implement Phase III of the narrowbanding license plan and require all users to transmit in 12.5 kHz channels at any speed or in 25 kHz channels at 19200 bps. Transmitting more slowly than 19200 bps in a 25 kHz channel will be illegal in the US. Furthermore, we expect that licenses for 25 kHz / 19200 bps operations will be very rare, if there are any at all. Unless you are a very special case, you should expect to be restricted to 12.5 kHz channels when any of the following occurs: you get a new license, your existing license is renewed or 2012 ends.



Here are answers to some common questions specific to Pacific Crest radios:

Q: I have a 25 kHz PDL radio. Is it 25 kHz only?

A: Yes. Only ADL-generation radios are user-configurable for operation at both 12.5 and 25 kHz. You can continue to use 25 kHz HPBs, LPBs, EDLs, RFMs, etc. until your license expires. However, you probably will not be able to renew your 25 kHz license and so will have to stop using your 25 kHz radio.

Q: I have a 25 kHz PDL radio. Can I legally use it after 1/1/13?

A: Only if you have a license after 1/1/13 for this mode of operation. These licenses will be hard to get and you will be restricted to a radio link rate of 19200 bps.

Q: How can I tell if my PDL radio transmits in 12.5 kHz or 25 kHz channels?

A: For LPBs, Sitecoms and EDLs, look at the model number on the side of the radio. If it ends in “12″ it’s a 12.5 kHz model. If it ends in “25″ it’s a 25 kHz model. For HPBs, look at the part number on the label. The following are 25 kHz HPB part numbers:

• A02531
• A02533
• A02535
• 56651-42-00
• 56651-44-00
• 56651-46-00
• 56651-44-10
• 56651-46-03

All other HPB part numbers are 12.5 kHz models. You can also connect your PDL radios to PDLCONF configuration software. The channel bandwidth is displayed on the Identification screen.

Q: All of my radios are receivers. How does any of this affect me?

A: It doesn’t directly affect you because the new regulations only restrict transmission. However, if you use a 25 kHz radio to receive data from a 12.5 kHz transmitter, you will pick up the desired signal but you also will receive signal from any radio within range that is transmitting on an adjacent 12.5 kHz channel. The mixing of the two signals will make both unintelligible. In practice, using a 25 kHz radio to receive a 12.5 kHz transmission doesn’t work well.

Q: Will I be able to continue using an ADL radio after 1/1/13 even though it is capable of transmitting in a 25 kHz channel?

A: Yes. Even if the FCC decides to forbid use of a radio that is physically capable of transmitting in a 25 kHz channel (not likely), Pacific Crest will release a version of firmware that will prevent such transmissions. The bottom line is that your ADL radio will remain legal even according to the most conservative interpretation of the FCC policy for 1/1/13.

Q: How fast can I operate in 12.5 kHz channels?

A: : This depends on the protocol and modulation type you select. The following table shows what link rates are supported by various combinations of protocol and modulation types:

Protocol Type	Modulation Type	Radio Link Rates (bps)
Transparent FST	4FSK	9600
Transparent EOT/EOC and Packet Switched	GMSK	4800
Transparent EOT/EOC and Packet Switched	4FSK	9600
TRIMTALK 450s	GMSK	4800, 8000
TRIMMARK II/IIe	GMSK	4800
TT450S (HW)	GMSK	4800
TRIMMARK 3	GMSK	9600 (USA)

Q: How does the narrowbanding policy affect my GPS receiver?

A: If your GPS receiver includes an internal UHF radio transmitter, the same FCC rules apply to it as to stand-alone transmitters: no more licenses after 1/1/11 and no more use (probably) after 1/1/13. To see what type of radio you have, use the receiver’s radio configuration software to connect to the radio. The channel bandwidth is usually displayed on an identification screen. If your GPS receiver’s internal radio only receives, there is no effect as the FCC’s narrowbanding policies affect only transmitters.

Q: My 25 kHz radio can transmit data at 19200 bps. This is the “equivalent efficiency” of 4800 bps in a 6.25 kHz channel, which satisfies the FCC’s narrowbanding requirement. So why do I need to switch to 12.5 kHz radios?

A: It is true that the FCC has defined narrowbanding as operating in 12.5 kHz or narrow channels OR transmitting at least 19200 bps in a 25 kHz channel. But that doesn’t mean they will automatically license any 25 kHz operation. In fact most observers believe they will NOT issue any more 25 kHz licenses except in special cases. The FCC has always been clear that their goal is to allow more licenses to be granted. The only way to do this in a limited frequency band is to require narrower channel bandwidths. Therefore, Pacific Crest believes it is prudent to switch to 12.5 kHz-compatible radios on or before the expiration of your 25 kHz license.

Q: Will there be a Phase IV – a requirement to use only 6.25 kHz channels?

A: Perhaps, but the FCC has issued no statements on this. Note that the FCC continued to license 25 kHz operation for 16 years after they announced the plan to migrate to 12.5 kHz. Will they issue only 6.25 kHz licenses beginning 16 years from today? Time will tell. You can be sure, however, that if this day ever comes, we’ll have a radio waiting.

Reproduced from Pacific Crest FCC Narrowband Requirements 022012.pdf document

CST/Berger Bell Mount with Swing Arm Tripod Adapter 5/8X11



CST/Berger Bell Mount with Swing Arm Tripod Adapter 5/8X11



Technical Details

• Replacement 5/8×11 for flat head tripod mount to hold instruments
• Includes swing arm for the aluminum tripods – Z60-3383i - Can be modifed to fit others with a file – please verify fitment



---

Product Description



CST is the leading manufacturer of Tripods in the USA. With the sheer number of different instruments on the market and their different mounting bases, CST has made it possible to adapt virtually any instrument to any tripod through the use of a variety of mounting adapters. CST has six different adapters to make mounting your instrument to any tripod possible.



60-1377O

60-13770

60-1377B

60-33831

60-3383i

Z60-3383I



Misc Survey Power Cables and Chargers for Data Collectors and GNSS GPS Receivers

ALL ITEMS SUBJECT TO PRIOR SALE – ORDER HERE

We cleaned out our 8,000 square foot warehouse getting ready to move into a bigger warehouse. We have lots of Ashtech and Thales Z-12 Z-Extreme and Z-Max power cables and download cables. Most items are PayPal only and are subject to prior sales. All sales are final, no warranty or guarantee is expressed or implied as these are end of life items or left over products.

Item 101 – Allegro CX – Color Screen with FAST Survey 2.3.3 – unlocked Total Station & GPS module $2500.00

??

Item 100 – Allegro CE – B&W Screen – Runs DOS – Windows CE Net 4.1 $1600.00

Item 99 – TDS Ranger CE – 133 MHz – B&W Screen – Has Survey Pro 2 unlocked $400

Item 98 – Allegro A/C Charger – 2 piece unit $125.00

Item 97 – Allegro A/C Charger – 2 piecwe unit $125.00

Item 96 – Allegro 12 Volt Charger – $45.00

Item 95 – Allegro 12 Volt Charger – $35.00

Item 94 – Allegro 12 Volt Charger – $45.00

Item 93 – Allegro A/C Charger – $50.00

Item 92 – Allegro A/C Charger – $45.00

Item 91 – Allegro A/C Charger – $25.00 – missing adapter

Item 90 – SAE 12 Volt Power Plug – Used – End has been cut – Includes SAE to Military Battery pigtail – $50

Item 52 – Pac Crest Radio PDL 4335 – 430-450 freq – has power cable and data cable, no whip – Used – $1500

Item 51 – Pac Crest Radio Battery Bag, with cables only (2-6′), A00644 $100 (N.O.S.)

Item 53 – AeroAntenna Aviation GPS AT2775-41W-TNCF-000-REG 40-NM, missing screws – $400

http://www.aeroantenna.com/html/aviation.html  - scuffs on one corner

Item 54 – AeroAntenna Aviation GPS AT2775-41W-TNCF-000-REG 40-NM – $600

http://www.aeroantenna.com/html/aviation.html  -  New in box

Item X – GPS Radio Antenna Tripod Leg Mount Ashtech Pac Crest (2 setups available) $75

Item 89 -  Pac Crest Radio SAE 12 Volt Power Cable  $25.00

Item 88 – SAE 12 Volt Power Cord, bare ends   $25.00

Item 87 – Serial Cable 051-0013-001-13026-X15074   $125.00

Item 86 - Serial Cable 051-0113-001-15514-X21277   $125.00

Item 85 – Military Power Cable Pigtail 730085- $50.00

Item 84 – Gender Bender DB9 051-0007-000  – $25.00

Item 83 – 12 Volt power Cord 730102 – $150.00

Item 82 – Ashtech Antenna Cable 70038402 – $50.00

Item 81 – Ashtech PC Download Cable – $175.00

Item 80 – Ashtech PC Download Cable Allegro CX to ProMark 500 – $200.00

Item 79 – Ashtech Serial Download Cable  700461 – $175.00

Item 78  Ashtech Serial to Serial Cable 730072 – $75.00

Item 77: Ashtech Open Pole Clamp – Full 360 degree hole pattern – 5198-052- $35.00

Item 76 : Ashtech Open Pole Clamp – Full 360 degree hole pattern – 5198-052- $35.00

Item 75 : Ashtech Open Pole Clamp – Full 360 degree hole pattern – 5198-052- $35.00

Item 74 : Ashtech Pole Bracket with Compass and Vial – Full 360 degree hole pattern -  $45.00

Item 73 : Ashtech Pole Bracket with Compass and Vial – Full 360 degree hole pattern -  $45.00

Item 72 : Ashtech Pole Bracket with Accessory Slot for Battery – Full 360 degree hole pattern -  $40.00

Item : 71 – Magellan Receiver to Receiver 7 Pin 730138   $150.00

Item : 70 – Magellan Receiver to Receiver 7 Pin 730138 – $150.00

Item  69 – Magellan DB9 to DB15 Coil Cord 730104  – $150.00

Item  68 – Magellan Mobile Mapper Patch Antenna AT65-330 – $25.00

Item 67 – Magellan Mobile Mapper Patch Antenna- $25.00

Item 66 – Ashetch A/C Charger 3 pin 1BC75A – $250.00

Item 65 -Ashetch Serail Cable 051-0113-001 : $150.00

Item 64 -Ashetch Beacon with Antenna 801-3011-01A  – $30.00

Does not power up, 12 volt adapter does light up LED when plugged in

Item 63 -Ashetch Z12 Battery Cable with Military End – $200.00

Item 62 -Ashetch Z12 Battery Cable with Military End – $200.00

Item 61 -Magellan Mobile Mapper CX PM3 7 pin to screw down mount – $150.00

Item 60 -Ashtech Power Supply Model 800886 – $125.00

Item 59 -Ashtech Z Xtreme Power Supply Cable 730134 – $125.00

ftp://ftp.ashtech.com/Cables/730134.PDF

Item : 58 -Ashtech Z12 Power Supply Model 341704 – $125.00

Item : 57 -Ashtech GPS Patch Antenna MMCX 1915PB-144/G- $25.00

Item 56 -Ashtech GPS Pole Bracket $50.00

Item 55 -5 Pin AC Power Supply A01007  $150.00

January 2012

Magellan Ashtech MobileMapper 6 Final Inventory

MobileMapper 6

As Stakemill nears the end of our MobileMapper 6 inventory we are saying goodbye to a thousand dollar sub meter unit.  While others claim to have hand held units to take the place of the MM6, no one has yet stepped up tot the plate with a true thousand dollar unit as rugged as the MM6, with free upgrades like the MM6 and the ability to create shape file as the Magellan Mobile Mapper did so well and for so long.  We do have a new Ashtech MobileMapper 10 that retails fro $1495.

Who will be the next Stake Supplier to start up?

It’s early 2012, we have seen so many people try to cut wood stakes and not make it, some last only a few months, some have gone a few years.  We want to be clear that stakes are not a product with a few week back log, in fact we have access to a few truck loads of finished product for those in need.  We do wonder what will happen to all the surplus equipment as we no longer purchase the saws used to make stakes as we have already cherry picked what was out there and purposely left the old out-dated and labor intensive machinery for those who failed.

We do see some operation being convinced that a supply yard or some large upcoming job will buy all the production they can produce, after all we get the same phone calls they do.  Stakemill is however looking for operations to do the final delivery for us, we can produce the stakes but with current fuel prices we cannot effectively get a small order from Tampa Bay to Jacksonville or Miami efficiently.  This is where we are looking for someone with a forklift, plenty of indoor warehouse space and reliable one ton trucks and hard-working employees to be our reseller.  Please contact Sean Scully at 727-538-0886 ext 101 with a copy of your business plan, we do require financial records proving your ability to carry the receivables, proof that adequate space has been secured and a good sales track record.

Laser Technology TruPulse Laser Range Finder Service and Repair Info from STAKEMILL

Laser Technology TruPulse Laser Range Finder Service and Repair Info from STAKEMILL

Have an LTI TruPulse in need of repair?  See info here

LTI Range Finders

Schonstedt Locator Service and Repair

Download the repair form here

We offer this service as a convenience to our loyal customers, most locators have extended warranties, please use the factory for fastest turn around times.

See if your unit is still under warranty

TruPulse Foliage Filter for ALL Range Finders 360R 360B 200B

Order LTI TruPulse Here
The increased thickness of the new TruPulse 360 R models rugged housing has required a modification to the Foliage Filter. Fits ALL 200, 200B, 260 260B & 360R models.
Simple lens snaps onto the TruPulse Range finders to improve measurememts with heavy foilage. Lens has a light blue tint, black bezel. Does require user setting to be changed internally.
The TruPulses Filter Targeting Mode allows the TruPulse to accurately penetrate heavy foliage. The Foliage Filter must be used in conjunction with the Filter Target Mode (Ξ Flt Ξ). The filter is placed over the TruPulse Receive Lens as shown below.


TruPulse Foliage Filter for ALL Range Finders 360R 360B 200B

Kenwood Rebate Program on ProTalk Portable Packages Just Announced

Order Kenwood ProTalk Radios Here

Kenwood has just announced a Rebate Promotion on the VHF ProTalk Portable Radio Package that Stakemill offers that runs from 2/1/12 through 4/30/12.   In summary the Promotion is as follows:

•  It includes the TK-3300U4P & TK-2300V4P ProTalk Portable Radio Packages (VHF & UHF 4-Channel ProTalk Packages).
•  $30.00 Rebate per unit with a minimum of six units (of the same model).
•  Rebate Program is for Business End-Users (maximum of 48 Radio Rebates per Business End User/Company).
•  Your customer must complete an online Rebate Form at an online site that Kenwood has established and send in a copy of that Form along with a copy of your Invoice along with the UPC Bar Code Labels for each Radio purchased.
•  A Rebate Check will be mailed to your customer within 10 weeks from submission of rebate request.

Promotion runs Feb. 1st through April 30th

Ask for a copy with your order or get details online at https://protalkrebates.kenwoodusa.com/Default.aspx

Shop Stakemill Measuring Tools on FACEBOOK

Stakemill has harnessed the power of Facebook and has uploaded our entire e-commerce site to Facebook, simply click the below link and be sure to LIKE US as well.  We offer online discounts to our Facebook friends, be sure to get yours today.

http://www.facebook.com/pages/Stakemill/316651845019846?v=app_136002413133082

Stakemill Now Offers LTI TruPulse 200B & 360B in New Color Choices – Orange, Maroon, Tan & Camo

LTI TruPulse

Stakemill Now Offers LTI TruPulse 200B & 360B in New Color Choices – Orange, Maroon, Tan & Camo – Order Here

LTI Range Finders

Recently we were presented with four stunning new TruPulse Laser Range Finder color choices.  These new rubberized finishes compliment numerous other GPS and Rugged PC manufacturers along with select hunting patterns. Now the hunters have a reason to buy the LTI’s, as a dual use distance meter, both at work and play.  When I first saw the Orange unit I thought oh boy, my Gators and UM fans will love this, then I saw the Garnet and Gold edition, or more like Maroon and Tan.  Either way my Florida customers will be happy to show their school colors while working, for some reason I have a feeling the Land Surveyors will be Orange with Blue accents and my Utility Contractors will be Garnet & Gold.

Don’t think any features have been removed to add these new color choices, in fact the new 200′s have enhanced firmware options, two-way Bluetooth, upgrade display and more features listed below.  You will love the new feel and look of these TruPulse models, available in 200, 200B, 360 & 360B versions.  Please call or see our website for complete details.

STAKEMILL and LTI TruPulse

Upgrade model features the same LCD as the 360B, bidirectional Bluetooth communications, auto shut off extended from 2 minutes to 30 minutes with Bluetooth enabled, 2D missing line routine will display HD, VD, SD, INC between two remote points, % Slope function alternative way of displaying inclination. Tactile diamond plate pattern rubber grips, enhanced eye piece rubber grip, enhanced diopter adjustment ring rubber and now supplied with a users CD Rom.

Stakemill Now Offers LTI TruPulse 200B & 360B in New Color Choices – Orange, Maroon, Tan & Camo – Order Here

Stakemill offers the LTI TruPulse in new color choices

Local eBay Seller Claims Online Sellers Have Run Instrument Prices Down For Him

In the 20+ years I have worked for Stakemill I have never heard such a ridiculous claim as I did today. We have been located in Largo for over 25 years, for the last four years we have been on the corner of US 19 North and 126th Ave (where they used to build the Checkers Drive Thru restaurants).  We have participated in online selling as well as selling through our retail store and with outside sales personnel going door to door.  About two years ago we had a new supplier or as we call a store-less supplier get into the Land Survey Instrument resale business in our city. Recently I had a discussion with a local supplier and we were discussing the visit of an instrument vendor stopping by to visit us this week and the comment they made about this local being out of business, one that I just saw selling on eBay.  It was confirmed that the eBay seller still exists, as they work from a storage shed located at a local church in our county, and they are still selling online only.  I was informed that this eBay seller thinks the Instrument vendor has ruined the market by having just anyone sell their line and they were one of the first to sell this line through their non-existent store and felt it unfair so they ceased dealings with this Instrument vendor.  So in a Readers Digest version of the story, its okay when you sell online and drive the price down, but when someone with no building, employees, utility bills, insurance bills, bank fees, merchant fees, employees salaries, vehicle expenses, phone system, forklifts, sign regulations, inventory reports, boxes, packing materials, network of PCs, service center, loaner units, demo models and oh yeah, inventory does it to them its unfair.

This has entreated me so much I have taken one of our GPS units from inventory to map out our location to their location and allow you the reader to see if this business has a legitimate complaint.  I will upload the map in Google Earth so you can see their facility and judge for yourself it they are a real supply shop as their name implies.  This is the first blog I have allowed you to comment on so please be truthful.

We also sell online, but we do not sell at cost, I know the end users wants a good deal but it is unfair when an established brick and mortar store provides a customer a product demo and the customer then goes back to the office and searches the product online and buys from a dot com that has minimal overhead.  They do not provide any of the support or product training but they close the sale and in turn have record sales levels with the manufactures thus making them appear to be movers and shakers in the industry when in fact they are in turn, degrading the product lines.

Please post your comments below

Pacific Crest ADL Vantage Radios at Stakemill

Order Here

ADL Vantage Pro

ADL Vantage Pro is an advanced, high speed, wireless data link built to survive the rigors of GNSS/RTK surveying and precise positioning. This sophisticated 35 Watt radio utilizes Pacific Crest’s latest generation Advanced Data Link (ADL) technology while remaining backward compatible with existing Pacific Crest, Trimble and other radios.  ADL Vantage Pro’s full-function user interface streamlines field configuration and troubleshooting so you can maintain maximum productivity. Its 35 Watts of power and advanced radio protocols offer the maximum range and throughput. For the most rugged and reliable digital data link, go with the Geomatics industry’s new standard in high-power wireless communications – ADL Vantage Pro.



Key Features

• Configurable Transmit Power from 2 to 35 Watts
• Multi-function user interface
• Heavy-Duty Construction
• Fully water- and dustproof
• 19200 Over-the-Air Link Rate without range degradation
• Advanced 40 MHz Bandwidth
• Software-Derived Channel Bandwidth

 ADL Vantage Pro Datasheet (English)  (Portuguese)

 ADL Vantage Pro FAQs (English)

 ADL Vantage/ADL Vantage Pro Getting Started Guide (English)

 ADL Vantage/ADL Vantage Pro User Guide (English)  (Portuguese)

 ADLCONF User Guide  (English)

NEW Orange TruPulse Laser Range Finders for Juniper Users

Order here

Orange TruPulse Range Finders

Stakemill has the Laser Technology TruPulse Range Finders in Orange to match the Archer and Mesa.  Stakemill has more hardware and software choices when it comes to the TruPulse units than any other supplier in Florida, Measureably Superior has joined Florida Superior in providing mapping solutions.

New ProMark 100, ProMark 200 Service Layer V 1.5.3 December 2011

Firmware Release Notes
Date: December 1st, 2011
Product: GNSS Service Layer for ProMark 100/200
Subject: New GNSS Service Layer release
Number: v1.5.3
Introduction
This release is a new version of GNSS Service Layer. It is an update of the latest version of Service Layer v1.5.2.
Service Layer v1.5.3 firmware is compatible with the following devices:

•  ProMark 100

•  ProMark 200

Components
New components are in bold
Release Version                 Version              GNSS
Previous version           V1.5.2                          W091                 Ht23
New version                V 1.5.3                        W092               Hv23

Upgrading instructions
To install new GNSS Service Layer on your device, you must establish a Microsoft ActiveSync connection between your PC and the GNSS receiver, copy the GNSS ServiceLayer v1.5.3 CAB file and execute it on the GNSS device. Then follow the instructions.
Languages supported
The following languages are supported with the version 1.5.3:

•  Chinese Simplified
•  Chinese Traditional
•  Japanese
•  Korean
•  English
•  French

•  German
•  Greek
•  Italian
•  Portuguese
•  Spanish

New features/Enhancements
This new GNSS Service Layer provides support to the following improvements:

•  Coordinate transformation messages support for MT 1021 – 1023
•  ProMark 800 receiver parameters added to receiver database

Resolved problems/Improvements
N/A

Recommendations
If your GNSS receiver is updated with the Service Layer v1.5.3, and you are using ProMark Field application, make sure that it is updated to v2.0 or further version.
